MC33074DTBR2G

Output Current :
Mounting Style : SMD/SMT
Packaging : Reel
Package / Case : TSSOP-14
Number of Channels : 4
Shutdown : No
Common Mode Rejection Ratio (Min) : 70 dB
Maximum Operating Temperature : + 85 C
Operating Supply Voltage : 5 V, 9 V, 12 V, 15 V, 18 V, 24 V, 28 V
Input Bias Current (Max) : 500 nA
Input Offset Voltage : 5 mV at 5 V
Slew Rate : 13 V/us at +/- 15 V


Parameters:

Technical/Catalog Information	MC33074DTBR2G
Vendor	ON Semiconductor (VA)
Category	Integrated Circuits (ICs)
Packaging	Cut Tape (CT)
Amplifier Type	General Purpose
Number of Circuits	4 - Quad
Package / Case	14-TSSOP
Slew Rate	13 V/s
Gain Bandwidth Product	4.5MHz
Current - Supply	1.9mA
Current - Output / Channel	30mA
Voltage - Supply, Single/Dual (±)	3 V ~ 44 V, ±1.5 V ~ 22 V
Output Type	-
-3db Bandwidth	-
Current - Input Bias	100nA
Operating Temperature	-40°C ~ 85°C
Voltage - Input Offset	1000V
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	MC33074DTBR2G MC33074DTBR2G MC33074DTBR2GOSCT ND MC33074DTBR2GOSCTND MC33074DTBR2GOSCT
