MC3303D

Operational Amplifiers - Op Amps Quad Low Power

product image

MC3303D Picture
See larger image
SeekIC No. : 00290537 Detail

MC3303D: Operational Amplifiers - Op Amps Quad Low Power

MC3303D Data Sheet

floor Price/Ceiling Price

US $ .35~.59 / Piece | Get Latest Price
Part Number:
MC3303D
Mfg:
Texas Instruments
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $.59
  • $.46
  • $.4
  • $.35
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Number of Channels : 4 Common Mode Rejection Ratio (Min) : 70 dB
Input Offset Voltage : 10 mV Input Bias Current (Max) : 500 nA
Operating Supply Voltage : 30 V Mounting Style : SMD/SMT
Package / Case : SOIC-14 Slew Rate : 0.6 V/us
Shutdown : No Maximum Operating Temperature : + 85 C
Packaging : Tube

Description

Output Current :
Mounting Style : SMD/SMT
Packaging : Tube
Number of Channels : 4
Shutdown : No
Common Mode Rejection Ratio (Min) : 70 dB
Slew Rate : 0.6 V/us
Maximum Operating Temperature : + 85 C
Package / Case : SOIC-14
Input Offset Voltage : 10 mV
Input Bias Current (Max) : 500 nA
Operating Supply Voltage : 30 V


Pinout

Connection Diagram


Specifications

Rating

 Symbol Value Unit
Power Supply Voltages
Single Supply
Split Supplies		 VCC
VCC, VEE		 36
±18		 Vdc
Input Differential Voltage Range (Note 1) VIDR ±36 Vdc
Input Common Mode Voltage Range
      (Notes 1, 2)		 VICR ±18 Vdc
Storage Temperature Range Tstg 55 to +125 °C
Operating Ambient Temperature Range
   MC3303
   MC3403		 TA 40 to +85
0 to +70		 °C
Junction Temperature TJ 150 °C



Parameters:

Technical/Catalog InformationMC3303D
VendorTexas Instruments
CategoryIntegrated Circuits (ICs)
PackagingTube
Amplifier TypeGeneral Purpose
Number of Circuits4 - Quad
Package / Case14-SOIC (3.9mm Width), 14-SOL
Slew Rate0.6 V/s
Gain Bandwidth Product1MHz
Current - Supply2.8mA
Current - Output / Channel30mA
Voltage - Supply, Single/Dual (±)5 V ~ 30 V, ±2.5 V ~ 15 V
Output Type-
-3db Bandwidth-
Current - Input Bias200nA
Operating Temperature-40°C ~ 85°C
Voltage - Input Offset2000V
Drawing Number296; 4040047-3; D; 14
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MC3303D
MC3303D
296 7033 5 ND
29670335ND
296-7033-5
