MC14093BDR2G

Number of Gates : 4
Maximum Operating Temperature : + 125 C
Mounting Style : SMD/SMT
Packaging : Reel
Package / Case : SOIC-14
Product : NAND
Number of Lines (Input / Output) : 2-IN / 1
Logic Family : 4000
Supply Voltage - Max : 18 V
Supply Voltage - Min : 3 V
Low Level Output Current : 4.2 mA (Min)
High Level Output Current : - 4.2 mA (Min)
Propagation Delay Time : 250 ns at 5 V, 100 ns at 10 V, 80 ns at 15 V


Parameters:

Technical/Catalog Information	MC14093BDR2G
Vendor	ON Semiconductor (VA)
Category	Integrated Circuits (ICs)
Number of Circuits	4 - Quad
Package / Case	14-SOIC (3.9mm Width), 14-SOL
Logic Type	NAND Gate - Schmitt Trigger
Packaging	Digi-Reel?
Mounting Type	Surface Mount
Number of Inputs	2
Current - Output High, Low	3.4mA, 3.4mA
Supply Voltage	3 V ~ 18 V
Operating Temperature	-55°C ~ 125°C
Voltage - Supply	3 V ~ 18 V
Drawing Number	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	MC14093BDR2G MC14093BDR2G MC14093BDR2GOSDKR ND MC14093BDR2GOSDKRND MC14093BDR2GOSDKR
