MC14081B

Features: Supply Voltage Range = 3.0 Vdc to 18 VdcAll Outputs BufferedCapable of Driving Two Low−power TTL Loads or One Low−power Schottky TTL Load Over the Rated Temperature Range.Double Diode Protection on All Inputs Except: Triple Diode Protection on MC14011B and MC14081BPin−f...

product image

MC14081B Picture
See larger image
SeekIC No. : 004415296 Detail

MC14081B: Features: Supply Voltage Range = 3.0 Vdc to 18 VdcAll Outputs BufferedCapable of Driving Two Low−power TTL Loads or One Low−power Schottky TTL Load Over the Rated Temperature Range.Doubl...

MC14081B Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
MC14081B
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

Supply Voltage Range = 3.0 Vdc to 18 Vdc
All Outputs Buffered
Capable of Driving Two Low−power TTL Loads or One Low−power
  Schottky TTL Load Over the Rated Temperature Range.
Double Diode Protection on All Inputs Except: Triple Diode
  Protection on MC14011B and MC14081B
Pin−for−Pin Replacements for Corresponding CD4000 Series
  B Suffix Devices
Pb−Free Packages are Available*


Pinout

Connection Diagram


Specifications

Symbol
Parameter
Value
Unit
VDD
DC Supply Voltage Range
−0.5 to +18.0
V
Vin, Vout

Input or Output Voltage Range
(DC or Transient)
−0.5 to VDD+ 0.5
V
Iin, Iout

Input or Output Current
(DC or Transient) per Pin
±10
mA
PD

Power Dissipation, per Package
(Note 1)
500
mW
TA

Ambient Temperature Range
−55 to +125
°C
Tstg

Storage Temperature Range
−65 to +150
°C
TL

Lead Temperature
(8−Second Soldering)
260
°C








Description

The B Series logic gates are constructed with P and N channel enhancement mode devices in a single monolithic structure (Complementary MOS). Their primary use is where low power
dissipation and/or high noise immunity is desired.
