Position: Home  > All Categories> Integrated Circuits (ICs) > MC14070BDR2

MC14070BDR2

IC GATE OR EXCLUSIVE CMOS 14SOIC

product image

MC14070BDR2 Picture
See larger image
SeekIC No. : 003545388 Detail

MC14070BDR2: IC GATE OR EXCLUSIVE CMOS 14SOIC

MC14070BDR2 Data Sheet

floor Price/Ceiling Price

US $ .08~.28 / Piece | Get Latest Price
Part Number:
MC14070BDR2
Mfg:
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • 250~500
  • 500~1000
  • 1000~5000
  • Unit Price
  • $.28
  • $.22
  • $.16
  • $.13
  • $.1
  • $.09
  • $.08
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/10/20

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Series: 4000B Manufacturer: ON Semiconductor
Logic Type: XOR (Exclusive OR) Number of Circuits: 4
Maximum Clock Frequency : 4 MHz Number of Inputs: 2
Features: - Voltage - Supply: 3 V ~ 18 V
Current - Quiescent (Max): 1µA Current - Output High, Low: 8.8mA, 8.8mA
Logic Level - Low: 1.5 V ~ 4 V Logic Level - High: 3.5 V ~ 11 V
Max Propagation Delay @ V, Max CL: 110ns @ 15V, 50pF Operating Temperature: -55°C ~ 125°C
Mounting Type: Surface Mount Supplier Device Package: 14-SOICN
Package / Case: 14-SOIC (0.154", 3.90mm Width)

Description

Mounting Type: Surface Mount
Number of Inputs: 2
Features: -
Current - Quiescent (Max): 1µA
Logic Type: XOR (Exclusive OR)
Operating Temperature: -55°C ~ 125°C
Package / Case: 14-SOIC (0.154", 3.90mm Width)
Number of Circuits: 4
Series: 4000B
Voltage - Supply: 3 V ~ 18 V
Logic Level - Low: 1.5 V ~ 4 V
Logic Level - High: 3.5 V ~ 11 V
Packaging: Cut Tape (CT)
Manufacturer: ON Semiconductor
Supplier Device Package: 14-SOICN
Current - Output High, Low: 8.8mA, 8.8mA
Max Propagation Delay @ V, Max CL: 110ns @ 15V, 50pF


Parameters:

Technical/Catalog InformationMC14070BDR2
VendorON Semiconductor (VA)
CategoryIntegrated Circuits (ICs)
Number of Circuits4 - Quad
Package / Case14-SOIC (3.9mm Width), 14-SOL
Logic TypeXOR (Exclusive OR)
PackagingDigi-Reel?
Mounting TypeSurface Mount
Number of Inputs2
Current - Output High, Low3.4mA, 3.4mA
Supply Voltage3 V ~ 18 V
Operating Temperature-55°C ~ 125°C
Voltage - Supply3 V ~ 18 V
Drawing Number*
Lead Free StatusContains Lead
RoHS StatusRoHS Non-Compliant
Other Names MC14070BDR2
MC14070BDR2
MC14070BDR2OSDKR ND
MC14070BDR2OSDKRND
MC14070BDR2OSDKR
