Supply Current
:
Maximum Power Dissipation
: 500 mW
Supply Voltage - Min
: 3 V
On Resistance (Max)
: 1050 Ohms
Maximum Operating Temperature
: + 125 C
Minimum Operating Temperature
: - 55 C
Number of Channels
: 4 Channel
Packaging
: Tube
Propagation Delay Time
: 40 ns
Supply Voltage - Max
: 18 V
Off Time (Max)
: 80 ns
Package / Case
: SOIC-14
On Time (Max)
: 120 ns
DescriptionThe MC14066BD consists of four independent switches capable of controlling eigher digital or analog signals.
Features of the MC14066BD are:(1)triple diode protection on all control inputs;(2)supply voltage range=3.0 Vdc to 18 Vdc;(3)linearized transfer characteristics;(4)low noise;(5)pin-for-pin replacement for CD4016,MC14016B;(6)for lower RON,use the HC4066 high-speed CMOS device.
The absolute maximum ratings of the MC14066BD can be summarized as:(1):the symbol is VDD,the parameter is DC supply voltage,the value is -0.5 to +18.0,the unit is V;(2):the symbol is Vin,VOUT,the parameter is input or output voltage (DC or transient),the value is -0.5 to VDD+0.5,the unit is V;(3):the symbol is Iin,the parameter is input current (DC or transient),per control pin,the value is ±10,the unit is mA;(4):the symbol is Isw,the parameter is switch through current,the value is ±25,the unit is mA; (5):the symbol is PD,the parameter is power dissipation,per package,the value is 500,the unit is mW;(6):the symbol is Tstg,the parameter is storage temperature,the value is -65 to +150,the unit is ;(7):the symbol is TL,the parameter is lead temperature (8-second soldering),the value is 260,the unit is .
Parameters: | Technical/Catalog Information | MC14066BD |
| Vendor | ON Semiconductor |
| Category | Integrated Circuits (ICs) |
| Type | Multiplexer |
| Voltage Supply Source | Dual Supply |
| Voltage - Supply, Single/Dual (±) | ±3 V ~ 18 V |
| Circuit | 4 x 1:1 |
| On-State Resistance | 280 Ohm |
| Mounting Type | Surface Mount |
| Package / Case | 14-SOIC (3.9mm Width), 14-SOL |
| Packaging | Tube |
| Current - Supply | 0.36A |
| Operating Temperature | -55°C ~ 125°C |
| Function | Multiplexer |
| Drawing Number | * |
| Lead Free Status | Contains Lead |
| RoHS Status | RoHS Non-Compliant |
| Other Names | MC14066BD
