PinoutSpecifications Symbol Parameter Value Unit VDD DC Supply Voltage 0.5 to + 18.0 V Vin,Vout Input or Output Voltage (DC or Transient) 0.5 to VDD + 0.5 V Iin,Iout Input or Output Current (DC or Transient), per Pin ± 10 mA PD Power Diss...
MC14025UB: PinoutSpecifications Symbol Parameter Value Unit VDD DC Supply Voltage 0.5 to + 18.0 V Vin,Vout Input or Output Voltage (DC or Transient) 0.5 to VDD + 0.5 V...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Symbol |
Parameter |
Value |
Unit |
VDD |
DC Supply Voltage |
0.5 to + 18.0 |
V |
Vin,Vout |
Input or Output Voltage (DC or Transient) |
0.5 to VDD + 0.5 |
V |
Iin,Iout |
Input or Output Current (DC or Transient), per Pin |
± 10 |
mA |
PD |
Power Dissipation, per Package† |
500 |
mW |
Tstg |
Storage Temperature |
65 to + 150 |
|
TL |
Lead Temperature (8Second Soldering) |
260 |
The UB Series logic gates are constructed with P and N channel enhancement mode MC14025UB in a single monolithic structure (Complementary MOS). Their primary MC14025UB use is where low power dissipation and/or high noise immunity is desired. The UB set of CMOS gates are inverting nonbuffered functions.
• Supply Voltage Range = 3.0 Vdc to 18 Vdc
• Linear and Oscillator Applications
• Capable of Driving Two Lowpower TTL Loads or One Lowpower Schottky TTL Load Over the Rated Temperature Range
• Double Diode Protection on All Inputs
• PinforPin Replacements for Corresponding CD4000 Series UB Suffix Devices
