MC10EL31

The MC10EL/100EL31 is a D flip-flop with set and reset. The device is functionally equivalent to the E131 device with higher performance capabilities.  With propagation delays and output transition times significantly faster than the E131 the EL31 is ideally suited for those applications, MC10EL/100EL31 require the ultimate in AC performance.

Both set and reset inputs of MC10EL/100EL31 are asynchronous, level triggered signals. Data enters the master portion of the flip-flop when clock is LOW and is transferred to the slave, and thus the outputs, upon a positive transition of the clock.
