MC-4R64CEE6C

The Direct Rambus RIMM MC-4R64CEE6B, 4R64CEE6C is a general-purpose high-performance memory module subsystem suitable for use in a broad range of applications including computer memory, personal computers, workstations, and other applications where high bandwidth and low latency are required.

MC-4R64CEE6B, 4R64CEE6C modules consists of four 128M Direct Rambus DRAM (Direct RDRAM™) devices(µPD488448).  These are extremely high-speed CMOS DRAMs organized as 8M words by 16 bits.  The use of Rambus Signaling Level (RSL) technology permits 600MHz, 711MHz or 800MHz transfer rates while using conventional system and board design technologies.

Direct RDRAM MC-4R64CEE6B, 4R64CEE6C are capable of sustained data transfers at 1.25 ns per two bytes (10 ns per sixteen bytes). The architecture of the Direct RDRAM enables the highest sustained bandwidth for multiple, simultaneous, randomly addressed memory transactions.  The separate control and data buses with independent row and column control yield over 95 % bus efficiency.  The Direct RDRAM's MC-4R64CEE6B, 4R64CEE6C 32 banks support up to four simultaneous transactions per device.
