MBRB2060CT

Schottky (Diodes & Rectifiers) 20A 60V

product image

MBRB2060CT Picture
See larger image
SeekIC No. : 00194169 Detail

MBRB2060CT: Schottky (Diodes & Rectifiers) 20A 60V

MBRB2060CT Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
MBRB2060CT
Mfg:
ON Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Product : Schottky Diodes Peak Reverse Voltage : 60 V
Forward Continuous Current : 20 A Max Surge Current : 150 A
Configuration : Dual Common Cathode Forward Voltage Drop : 0.95 V
Maximum Reverse Leakage Current : 150 uA Operating Temperature Range : - 65 C to + 175 C
Mounting Style : SMD/SMT Package / Case : D2PAK
Packaging : Tube

Description

Recovery Time :
Maximum Power Dissipation :
Maximum Reverse Leakage Current : 150 uA
Mounting Style : SMD/SMT
Product : Schottky Diodes
Packaging : Tube
Forward Continuous Current : 20 A
Peak Reverse Voltage : 60 V
Operating Temperature Range : - 65 C to + 175 C
Configuration : Dual Common Cathode
Max Surge Current : 150 A
Package / Case : D2PAK
Forward Voltage Drop : 0.95 V


Specifications

Rating Symbol Value Unit
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
 VRRM
VRWM
VR		 60
 Volts
Average Rectified Forward Current
(Rated VR) TC = 110 Total Device		 IF(AV) 10
20		 Amps
Peak Repetitive Forward Current, PerLeg
(Rated VR,Square Wave,20 kHz) TC =100
 IFRM 20 Amps
Non-repetitive Peak Surge Current
(Surge applied at rated load conditions,halfwave,single phase, 60Hz)
 IFSM 150 Amps
Peak Repetitive Reverse Surge Current (2.0 s, 1.0 kHz) IRRM 0.5 Amp
Storage Temperature Tstg 65 to+175 °C
Operating Junction Temperature TJ 65 to +150 °C
Voltage Rate of Change (Rated VR) dv/dt 10000 V/s





Description

MBR2035CT thru MBRB2060CT datasheet
