MBRB20200CT

Recovery Time :
Maximum Power Dissipation :
Mounting Style : SMD/SMT
Product : Schottky Diodes
Packaging : Tube
Forward Continuous Current : 20 A
Peak Reverse Voltage : 200 V
Forward Voltage Drop : 0.9 V
Operating Temperature Range : - 65 C to + 150 C
Configuration : Dual Common Cathode
Max Surge Current : 150 A
Maximum Reverse Leakage Current : 1000 uA
Package / Case : D2PAK


Specifications

Rating	Symbol	Value	Unit
Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage	VRRM VRWM VR	200	Volts
Average Rectified Forward Current                  Per Leg (Rated VR) TC = 125°C                           Per Package	IF(AV)	10 20	Amps
Peak Repetitive Forward Current, PerLeg (Rated VR,Square Wave,20 kHz) TC =90°C	IFRM	20	Amps
Nonrepetitive Peak Surge Current (Surge applied at rated load conditions,halfwave,single phase, 60Hz)	IFSM	150	Amps
Peak Repetitive Reverse Surge Current (2.0 s, 1.0 kHz)	IRRM	1.0	Amp
Operating Junction Temperature	Tstg	65 to+150	°C
Storage Temperature	TJ	65 to +175	°C
Voltage Rate of Change (Rated VR)	dv/dt	10,000	V/s

Parameters:

Technical/Catalog Information	MBRB20200CT
Vendor	ON Semiconductor
Category	Discrete Semiconductor Products
Diode Type	Schottky
Diode Configuration	1 Pair Common Cathode
Voltage - DC Reverse (Vr) (Max)	200V
Current - Average Rectified (Io) (per Diode)	10A
Voltage - Forward (Vf) (Max) @ If	900mV @ 10A
Current - Reverse Leakage @ Vr	1mA @ 200V
Reverse Recovery Time (trr)	-
Speed	Fast Recovery =< 500ns, > 200mA (Io)
Mounting Type	Surface Mount
Package / Case	D&sup2;Pak, SMD-220, TO-263 (2 leads + tab)
Packaging	Tube
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	MBRB20200CT MBRB20200CT MBRB20200CTOS ND MBRB20200CTOSND MBRB20200CTOS
