MB88101A

Features:

• 4-channel analog input
• One analog input channel selectable for conversion by external control
• CR-type successive approximation system with a sample-and-hole circuit
• 12-bit resolution
• Serial output of 12-bit digital data
• Capable of continuous conversion (continuous conversion mode)
• MSB or LSB selectable for serial output
• CMOS process
• Package options of 16-pin DIP, SSOP, and SOP available


Pinout




Specifications




Description

The MB88101A is an analog-to-digital converter that converts its analog input to a 12-bit digital value and outputs
it as serial data.
The MB88101A employs a successive approximation method for A/D conversion.
The MB88101A has four input channels selectable for analog input under control of the dedicated external pins.
The MB88101A can be switched to a mode for continuous A/D conversion, in which it outputs serial data from the
MSB or LSB selectable depending on the mode setting.
