MB154W

Forward Continuous Current :
Power Dissipation :
Product : Single Phase Bridge
Maximum Operating Temperature : + 150 C
Mounting Style : Through Hole
Packaging : Tube
Maximum Reverse Leakage Current : 10 uA
Peak Reverse Voltage : 400 V
Maximum RMS Reverse Voltage : 280 V
Forward Voltage Drop : 1.1 V
Max Surge Current : 300 A
Height : 11.23 mm
Length : 28.7 mm
Width : 28.7 mm
Package / Case : MB-W


Features:

* Surge overload ratings-300 Amperes
* Metal case for Maximum Heat Dissipation
* Low forward voltage drop


Specifications

Ratings at 25 ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.


Parameters:

Technical/Catalog Information	MB154W
Vendor	Micro Commercial Co
Category	Discrete Semiconductor Products
Diode Type	Single Phase
Package / Case	MB-35W
Packaging	Bulk
Reverse Recovery Time (trr)	-
Speed	Standard Recovery >500ns, > 200mA (Io)
Current - DC Forward (If)	15A
Voltage - Peak Reverse (Max)	400V
Mounting Type	Through Hole
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	MB154W MB154W MB154WMS ND MB154WMSND MB154WMS
