MAX2607

V_CC to GND............................................................-0.3V to +6V
IND to GND ...............................................-0.6V to (V_CC + 0.3V)
TUNE to GND .............................................-0.3V to (V_CC + 0.3V)
OUT+, OUT- to GND ..................................-0.3V to (V_CC + 0.6V)
Continuous Power Dissipation (T_A = +85°C)
   6-Pin SOT23 (derate 8.7mW/°C above +70°C).........696mW
Operating Temperature Range .......................-40°C to +85°C
Junction Temperature...................................................+150°C
Storage Temperature Range ........................-65°C to +150°C
Lead Temperature (soldering, 10s) ..............................+300°C

Stresses beyond those listed under "Absolute Maximum Ratings" may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of the specifications is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.

The MAX2605MAX2609 are compact, high-performance intermediate-frequency (IF) voltage-controlled oscillators (VCOs) designed specifically for demanding portable wireless communication systems. They combine monolithic construction with low-noise, low-power operation in a tiny 6-pin SOT23 package.

These  MAX2605MAX2609  low-noise VCOs feature an on-chip varactor and feedback capacitors that eliminate the need for external tuning elements, making the MAX2605MAX2609 ideal for portable systems. Only an external inductor is required to set the oscillation frequency. In addition, an integrated differential output buffer is provided for driving a mixer or prescaler. The buffer output is capable of supplying up to -8dBm (differential) with a simple power match. It also provides isolation from load impedance variations.

The MAX2605MAX2609 operate from a single +2.7V to +5.5V supply and offer low current consumption. These IF oscillators can cover the 45MHz to 650MHz frequency range.
