MASWSM0015

Gallium arsenide integrated circuits are ESD sensitive and can be damaged by static electricity. Use proper ESD precautions when handling these devices.

M/A-COM's MASWSM0015 is a high frequency 2 x 2 switch optimized for 802.11a WLAN and fixed wireless access applications. It has low insertion loss, making it an ideal candidate for use as a double antenna T/R switch or as a switch matrix building block. Optimized for use from 4. 5 to 6.0 GHz, it requires no off chip components, and is internally DC blocked at the RF inputs.

The MASWSM0015 is fabricated using M/A-COM's P-HEMT switch technololgy for low insertion loss, low supply voltage, and fast switching speed.
