MAS9078

Features:

• Highly Sensitive AM Receiver, 0.4 VRMS typ.
• Wide Supply Voltage Range from 1.1 V to 3.6 V
• Very Low Power Consumption
• Power Down Control
• Fast Startup
• Only a Few External Components Necessary
• Control for AGC On
• Wide Frequency Range from 40 kHz to 100 kHz
• High Selectivity by Quartz Crystal Filter
• Die and TSSOP-16 Package


Application

• Time Signal Receiver WWVB (USA), JJY (Japan), DCF77 (Germany) and MSF (UK)
• Receiver for ASK Modulated Data Signals


Specifications

Parameter	Symbol	Conditions	Min	Max	Unit
Supply Voltage	VDD-VSS		-0.3	5.0	V
Input Voltage	VIN		VSS-0.3	VDD+0.3	V
Power Dissipation	PMAX			100	mW
Operating Temperature	TOP		-20	70
Storage Temperature	TST		-40	120

Description

The MAS1016A and MAS1016B, MAS9078  AM-Receiver chip is a highly sensitive, simple to use AM receiver specially intended to receive time signals in the frequency range from 40 kHz to 100 kHz. Only a few external components are required for time signal receiver. The MAS1016A and MAS1016B, MAS9078  circuit has preamplifier, wide range automatic gain control, demodulator and output comparator built in. The output signal can be processed directly by an additional digital circuitry to extract the data from the received signal. The control for AGC (automatic gain control) can be used to switch AGC on or off if necessary. Unlike MAS1016A and MAS1016B, MAS9078 does not require AGC control procedure in WWVB and JJY systems.
