M95040

Features:

Compatible with SPI Bus Serial Interface
  (Positive Clock SPI Modes)
Single Supply Voltage:
  4.5 to 5.5V for M950x0
  2.5 to 5.5V for M950x0-W
  1.8 to 5.5V for M950x0-R
High Speed
  10MHz Clock Rate, 5ms Write Time
Status Register
BYTE and PAGE WRITE (up to 16 Bytes)
Self-Timed Programming Cycle
Adjustable Size Read-Only EEPROM Area
Enhanced ESD Protection
More than 1 Million Erase/Write Cycles
More than 40-Year Data Retention


Specifications

Symbol	Parameter	Min	Max	Unit
TSTG	Storage Temperature	65	150	°C
TLEAD	Lead Temperature during Soldering1	See note1		°C
VO	Output Voltage	0.50	VCC+0.6	V
VI	Input Voltage	0.50	6.5	V
VCC	Supply Voltage	0.50	6.5	V
VESD	Electrostatic Discharge Voltage (Human Body model)2	4000	4000	V

Note:
1.Compliant with JEDEC Std J-STD-020B (for small body, Sn-Pb or Pb assembly), the ST ECOPACK^®7191395 specification, and
the European directive on Restrictions on Hazardous Substances (RoHS) 2002/95/EU.
2.AEC-Q100-002 (compliant with JEDEC Std JESD22-A114A, C1=100pF, R1=1500Ω, R2=500Ω)


Description

The M95040 is a 4 Kbit (512 x 8) electrically erasable programmable memory (EEPROM), accessed by a high speed SPI-compatible bus. The other members of the family (M95020 and M95010) are identical, though proportionally smaller (2 and 1Kbit, respectively).Each device is accessed by a simple serial interface that is SPI-compatible. The bus signals are C,D and Q, as shown in Table 2.and Figure 2.The device is selected when Chip Select (S) is taken Low. Communications with the device can be interrupted using Hold (HOLD). WRITE instructions are disabled by Write Protect (W).
