M66236FP

• 5V single power supply (5V ±5%)
• Frequency band: 12 ~ 25MHz
• Synchronizing precision (jitter): ±5ns
• Output types
(1) Output of the same frequency as input clock, and its in- version
(2) 1/2 divider clock output and its inversion
(3) One-shot pulse output
(4) Continuous clock output
• Noise in the positive direction to trigger input is removed by built-in noise killer circuit

M66236 is produced using the silicon gate CMOS process. It is able to output clock input signal in sync with optional exter- nal trigger input signal.

The M66236 features excellent synchronizing precision (jitter) over a wide frequency band range.
