M61516FP

Electronic Volume ............(1)8 channel Independent Electronic Volume with High
                                             Voltage Transistor. (0~-92dB/1dBstep,-95,- dB)
                                        (2)Built-in Zero-Crossing Detector Circuit for reduce click
                                             noise at changing volume value.
Tone Control .................. (1)Bass/Treble,0~ 10dB/2dBstep
                                        (2)Add a Bypass Mode/Tone Mode changing SW
Input Selector ................ (1)Front L/R channel 10 Input Selector
                                        (2)2 sets of multi channel input
REC Output  .....................4 Lines REC Output (Both L and R channels)
Input attenuator  .............0/-3/-6/-9/-12dB
Output Gain Control ........ 0/+3/+6/+9/+12dB
Balance Out......................Built-in Balance out (for ADC)
Loudness *1.....................Built-in Loudness circuit of center tap type in FL/FRch
                *1 Balance output and loudness function can't be used at the same time.
