M61323SP

Features: Frequency band : RGB........................................250MHz: H,V...........................10KHz to 200KHzInput level:RGB............................................0.7Vp-p(Typ.) H,V TTL input ....................3 to 5Vo-p (bipolar)Only the G channel is provided with Sync-on vide...

product image

M61323SP Picture
See larger image
SeekIC No. : 004406426 Detail

M61323SP: Features: Frequency band : RGB........................................250MHz: H,V...........................10KHz to 200KHzInput level:RGB............................................0.7Vp-p(Typ.) H,...

M61323SP Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
M61323SP
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

Frequency band : RGB........................................250MHz
                          : H,V...........................10KHz to 200KHz
Input level:RGB............................................0.7Vp-p(Typ.)
                  H,V TTL input ....................3 to 5Vo-p (bipolar)

Only the G channel is provided with Sync-on video output.The TTL format is adopted for HV output.


Application

Display monitor


Pinout

Connection Diagram


Specifications

Symbol
Parameter
Ratings
Unit
Vcc Clamping-emitter voltage
7.0
V
Pd Power dissipation
1603(SP),1068(FP)
mW
Topr Operating temperature
-20 to +85 (SP) , -20 to +75 (FP)
°C
Tstg Storage temperature
-40 to +150
Surge Electrostatic discharge
+200
V
Vopr Recommended supply voltage
5.0
V
Vopr' Recommended supply voltage range
4.75to5.25
V



Description

The M61323SP/FP is a semiconductor integrated circuit for the RGBHV interface. The device features switching signals
input from two types of image sources and outputting the signals to the CRT display,etc. Synchronous signals,meeting a frequency band of 10KHz to 200KHz, are output at TTL. The frequency band of video signals is 250MHz,acquiring high-resolution images, and are optimum as an interface IC with high-resolution CRT display and various new media.

The M61323SP/FP keeps the power saving mode, and it can reduce ICC about 10mA under the condition that all Vcc are supplied.
