M52755SP

• Frequency band:RGB......................................................250MHz HV.............................................10Hz to 200kHz Input level:RGB.........................................................0.7VP-P (typ.) HV TTL input.............................3.5VO-P (both channel)
• Only the G channel is provided with sync-on video output.
• The TTL format is adopted for HV output.

The M52755SP is a semiconductor integrated circuit for the RGBHV interface. The device features switching signals input from two types of image sources and outputting the signals to the CRT display, etc. Synchronous signals, meeting a frequency band of 10kHz to 200kHz, are output at TTL. The frequency band of video signals is 250MHz, acquiring high-resolution images, and are optimum as an interface IC with high-resolution CRT display and various new media.
