M52746SP

·Frequency Band Width: RGB 200 MHz (at -3dB)
                                         OSD 80 MHz
   Input : RGB                  0.7 Vp-p (Typ)
              OSD light          4 Vp-p minimum (positive)
              OSD harf          2.5Vp-p minimum (positive)
                                      3.0Vp-p maximum (positive)
         BLK(for OSD)         3 Vp-p minimum (positive)
              Retrace BLK      3 Vp-p minimum (positive)
   Output : RGB               5.5 Vp-p (maximum)
                 OSD               5 Vp-p (maximum)
 ·Main Contrast and Sub Contrast can be controlled by I2C Bus

M52746SP is Semiconductor Integrated Circuit for CRT Display Monitor.It includes OSD Blanking,OSD Mixing,Retrace
Blanking,Wide Band Amplifre,Brightness Control.Main/Sub Contrast and OSD AdjustFunction can be controlled by I2C Bus.
