M5226P

The M5226P is a 5-element graphic IC best suited to audio systems. It has a built-in 5-element resonance circuits with transistor system and an output OP amp. The IC can be used in hybrid ICs and compact sets of high-density assemblies.Its applications include radio cassette tape players, car audio systems, and music centers. It has five unique features; The first one is the number of part can be reduced drastically for compact size. The second oen is Graphic equalizer can be easily composed. The third one is low distortion. The forth one is low noise.The fifth one is large allowable input voltage.

There are some recommeded operating conditions about M5226P. Supply votlage range is 4 V to 20 V. Rated supply voltage is 20 V. Rated power dissipation is 700 mW(P).Absolute maximum ratings: Supply voltage(Vcc) is 20 V. Load current(ILP) is 30 mA . Power dissipation(Pd) is 550(FP)/1000(DIP) mW.Operating temperature(Topr) is -20 to 75.Storage temperature range(Tstg) is -55 to +125.Otherwise, there are also some electrical charactersitics about it.Circuit current(Icc) is 3.0 mA mA,5.2 mA typ and 8.0 mA max when Vin is 0.Total harmonic distortion(THD) is 0.02% typ and 0.1% max when Vin is 1 Vrms and f is 1 KHz. Output noise voltage(Vno) is 5.0 uVrms typ and 20 uVrms max(input short BW:10Hz to 30kHz(3 dB)flat).
