M51327P

The M51327P is a kind of semiconductor integrated circuit including an analog switch designed for use in a video system. It contains two audio switches and one video switch. Each switch has three inputs and can be independently controlled. It is widely used in video equipment.

There are some features of M51327P as follows: (1)video and stereo sound switches in one package; (2)wide frequency range (video switch): 10 MHz DC; (3)high seperation (video): crosstalk 55 dB (typ) @ 5 MHz.

The following is about the absolute maximum ratings of M51327P: (1)VCC, supply voltage: 14 V; (2)VIS, input signal voltage: 6 V; (3)VIC, input control voltage: VCC V; (4)Pd, power dissipation: 1.25 V; (5)K, thermal derating: 12.5 mW/; (6)Topr, operating temperature range: -20 to +75; (7)Tstg, storage temperature range: -40 to +125.
