M402101BP

The M402101BP has the following features including Internal control latch circuit;Internal level-shifter circuit;Good crosstalk characteristics-100dB (@f=3kHz);5V control logic.

The M402101BP is a semiconductor integrated circuit consisting of a 4X8 cross point switch capable of selecting 32 analog switches with 5 address inputs as well as 2 types of control signals.The input address signals(A,B, C, D, E) are five-bit binary coded. When the STROBE input is high, the switch that corresponds to the value of the input address signals is selected. If, at this time, the DATA IN input is high, the switch is turned on and until DATA IN is pulled lov. If the DATA IN is low, the switch is turned off and becomes in high-impedance state. When the STROBE becomes low,any of the switch conditions are not changed. The internal level-shifter makes possible to handle 15Vp-p analog signals by 5V control logic signals.

The M402101BP described in this document are designed, developed and manufactured as contemplated for general use, including without limitation, ordinary industrial use, general office use, personal use, and household use, but are not designed, developed and manufactured as contemplated (1) for any use that includes fatal risks or dangers that, unless extremely high safety is secured, could have a serious effect to the public, and could lead directly to death, personal injury, severe physical damage or other loss (i.e., nuclear reaction control in nuclear facility, aircraft flight control, air traffic control, mass transport control, medical life support system, missile launch control in weapon system), or (2) for any use where chance of failure is intolerable (i.e., submersible repeater and artificial satellite).

At present there is not too much information about this model.If you are willing to find more  about M402101BP, please pay attention to our web! We will promptly update the relevant information.
