M36DR232A

Note: 1. Except for the rating "Operating Temperature Range", stresses above those listed in the
              Table " Absolute Maximum Ratings" may cause permanent damage to the device. These are
              stress ratings only and operation of the device at these or any other conditions above those
              indicated in the Operating sections of this specification is not implied. Exposure to Absolute
              Maximum Rating conditions for extended periods may affect device reliability. Refer also to the
              STMicroelectronics SURE Program and other relevant qualitydocuments.
         2. Minimum voltage may undershoot to 2V during transition and for less than 20ns.
         3. Depends on range.
         4. V_DD = V_DDS = V_DDF.

The M36DR232 is a multichip memory device containing a 32 Mbit boot block Flash memory and a 4Mbit of SRAM. The M36DR232 is offered in a Stacked LFBGA66 (0.8 mm pitch) package.

The two components M36DR232 are distinguished by use with three chip enable inputs: EF for the Flash memory and, E1S and E2S for the SRAM. The two components M36DR232 are also separately power supplied and grounded.
