M1MA141KT1

Product : Switching Diodes
Packaging : Reel
Configuration : Single
Peak Reverse Voltage : 80 V
Recovery Time : 3 ns
Maximum Reverse Leakage Current : 0.1 uA
Forward Voltage Drop : 1.2 V
Operating Temperature Range : + 150 C
Max Surge Current : 1 A
Package / Case : SC-70-6
Maximum Power Dissipation : 0.3 W
Forward Continuous Current : 0.24 A


Features:

• Fast t_rr , < 3.0 ns
• Low C_D , < 2.0 pF
• Available in 8 mm Tape and Reel
   Use M1MA151/2AT1 to order the 7 inch/3000 unit reel.
   Use M1MA151/2AT3 to order the 13 inch/10,000 unit reel.


Specifications

Rating		Symbol	Value	Unit
Reverse Voltage	M1MA151WAT1	VR	40	Vdc
	M1MA152WAT1		80
Peak Reverse Voltage	M1MA151WAT1	VRM	40	Vdc
	M1MA152WAT1		80
Forward Current		IF	100	mAdc
Peak Forward Current		IFM	225	mAdc
Peak Forward Surge Current		IFSM(1)	500	mAdc

Description

These Silicon Epitaxial Planar Diodes M1MA141KT1 are designed for use in ultra high speed switching applications. These devices are housed in the SC-59 package which is designed for low power surface mount applications.
