LZ21N3V

Features: ` Optical size : 8.08 mm (aspect ratio 4 : 3) ` Interline scan format ` Square pixel ` Number of effective pixels : 1 650 (H) x 1 250 (V) ` Number of optical black pixels -Horizontal : 2 front and 52 rear -Vertical : 3 front and 2 rear ` Number of dummy bits -Horizontal : 28 - Ver...

product image

LZ21N3V Picture
See larger image
SeekIC No. : 004403756 Detail

LZ21N3V: Features: ` Optical size : 8.08 mm (aspect ratio 4 : 3) ` Interline scan format ` Square pixel ` Number of effective pixels : 1 650 (H) x 1 250 (V) ` Number of optical black pixels -Horizontal...

LZ21N3V Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
LZ21N3V
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/7

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

  ` Optical size : 8.08 mm (aspect ratio 4 : 3)
  ` Interline scan format
  ` Square pixel
  ` Number of effective pixels : 1 650 (H) x 1 250 (V)
  ` Number of optical black pixels
       - Horizontal : 2 front and 52 rear
       - Vertical : 3 front and 2 rear
  ` Number of dummy bits
      -Horizontal : 28
      - Vertical : 2
  ` Pixel pitch : 3.95 µm (H) x 3.95 µm (V)
  ` R, G, and B primary color mosaic filters
  ` Supports monitoring mode
  ` Low fixed-pattern noise and lag
  ` No burn-in and no image distortion
  ` Blooming suppression structure
  ` Built-in output amplifier
  ` Built-in overflow drain voltage circuit and reset gate voltage circuit
  ` Variable electronic shutter
  ` Packages
      - LZ21N3V : 20-pin half-pitch WDIP [Plastic] (WDIP020-P-0500) Row space : 12.20 mm
      - LZ21N3VS : 20-pin half-pitch WSOP [Plastic] (WSOP020-P-0525)


Pinout

Connection Diagram


Specifications

PARAMETER
SYMBOL
RATING
UNIT
NOTE
Output transistor drain voltage
VOD
0 to +15
V
Overflow drain voltage
VOFD
Internal output
V
1
Reset gate clock voltage
VRS
Internal output
V
2
Vertical shift register clock voltage
VV
VPW to +15
V
Horizontal shift register clock voltage
VH
-0.3 to +12
V
Voltage difference between P-well and vertical clock
VPW-VV
-24 to 0
V
Voltage difference between vertical clocks
VV-VV
0 to +15
V
3
Storage temperature
TSTG
-40 to +85
Ambient operating temperature
TOPR
-20 to +70

NOTES :
1. Do not connect to DC voltage directly. When OFD is connected to GND, connect VOD to GND. Overflow drain clock is applied below 22 Vp-p.
2. Do not connect to DC voltage directly. When RS is connected to GND, connect VOD to GND. Reset gate clock is applied below 8 Vp-p.
3. When clock width is below 10 µs, and clock duty factor is below 0.1%, voltage difference between vertical clocks will be below 22 V.


Description

The LZ21N3V/VS are 1/2-type (8.08 mm) solidstate image sensors that consist of PN photodiodes and CCDs (charge-coupled devices). With approximately 2 140 000 pixels (1 704 horizontal x 1 255 vertical), the sensor provides a stable highresolution color image.
