LTR-3208E: Photodetector Transistors Phototransistor PTX 5mm, Filtr

LTR-3208E Data Sheet

US $ .11~.16 / Piece | Get Latest Price

Part Number:: LTR-3208E
Mfg:: Lite-On
Supply Ability:: 5000

Price Break

Qty
0~1
1~10
10~50
50~100

Unit Price
$.16
$.14
$.12
$.11

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

LTR-209 evaluate
US $.14 - .19 / Piece

Photodetector Transistors Phototrans Clear
LTR-301 evaluate
US $.09 - .13 / Piece

Photodetector Transistors Phototrans Clear
LTR-306 evaluate
US $.09 - .13 / Piece

Photodetector Transistors Phototrans Trans

Product Details

Quick Details

Maximum Power Dissipation :	100 mW	Maximum Dark Current :	100 nA
Package / Case :	T-1 3/4

Description

Maximum Power Dissipation : 100 mW
Maximum Dark Current : 100 nA
Package / Case : T-1 3/4

Features:

Wide range of collector currents.
Lens for high sensitivity.
Low cost plastic package.

Specifications

Parameter	Maximum Rating100	Unit
Power Dissipation	100	mW
Collector-Emitter Voltage	30	V
Emitter-Collector Voltage	5	V
Operating Temperature Range	-40°C to +85°C
Storage Temperature Range	-55 °Cto +100°C
Lead Soldering Temperature [1.6mm (.063 in.) from body]	260°C for 5 Seconds

Description

The LTR-3208 series consist of a NPN silicon phototransistor mounted in a lensed, clear plastic, end looking package. The lensing effect of the package allows an acceptance half angle of 10 measured from the optical axis to the half power point. This series is mechanically and spectrally matched to the LTE-3271T/ LTE-3371T series of infrared emitting diodes. The LTR- 3208E is a special dark plastic package that cut the visible light and suitable for the detectors of infrared application.

Parameters:

Technical/Catalog Information	LTR-3208E
Vendor	Lite-On Inc
Category	Sensors, Transducers
Voltage - Collector Emitter Breakdown (Max)	30V
Current - Collector (Ic) (Max)	3.12mA
Current - Dark (Id) (Max)	100nA
Power - Max	100mW
Orientation	Top View
Mounting Type	Through Hole
Package / Case	T 1 3/4
Wavelength	940nm
Viewing Angle	20°
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	LTR 3208E LTR3208E 160 1031 ND 1601031ND 160-1031
