LTH-301-07, US $ .23-.27 , Lite-On, LTH-301-07 DataSheet download, circuit diagram from SeekIC.com

Optical Switches, Transmissive, with Phototransistor Output Photointerrupter Phototransistor

See larger image

SeekIC No. : 0086461 Detail

LTH-301-07: Optical Switches, Transmissive, with Phototransistor Output Photointerrupter Phototransistor

LTH-301-07 Data Sheet

US $ .23~.27 / Piece | Get Latest Price

Part Number:: LTH-301-07
Mfg:: Lite-On
Supply Ability:: 5000

Price Break

Qty
0~3250
3250~5000
5000~10000

Unit Price
$.27
$.25
$.23

Processing time
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2025/12/18

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

LTH-010-01-G-D-A-K evaluate
US $3.7 - 3.7 / Piece

TERM STRIP LP 20POS SMD
LTH-030-01-G-D-A-K evaluate
US $4.52 - 4.52 / Piece

TERM STRIP LP 60POS SMD
LTH-050-01-G-D-A-K evaluate
US $5.29 - 5.29 / Piece

TERM STRIP LP 100POS SMD

Product Details

Description

Series: -
Sensing Method: Reflective
Output Type: Phototransistor
Mounting Type: Through Hole
Packaging: Bulk
Current - DC Forward (If): 60mA
Current - Collector (Ic) (Max): 20mA
Voltage - Collector Emitter Breakdown (Max): 30V
Sensing Distance: 0.2" (5.08mm)
Manufacturer: Lite-On Inc
Response Time: 3µs, 4µs
Package / Case: Module, PC Pins, Slot Type

Features:

* NON-CONTACT SWITCHING.
* FOR DIRECT PC BOARD OR DUAL-IN-LINE SOCKET MOUNTING.
* FAST SWITCHING SPEED.

Specifications

PARAMETER	MAXIMUM RATING	UNIT
IR Diode Continuous Forward Current	60	mA
IR Diode Reverse Voltage	5	V
Transistor Collector Current	20	mA
Transistor Power Dissipation	75	mW
IR Diode Peak Forward Current (Pulse Wide = 10 S, 300 pps)	1	A
Diode Power Dissipation	100	mW
Phototransistor Collector-Emitter Voltage	30	V
Phototransistor Emitter-Collector Voltage	5	V
Operating Temperature Range	-25 to + 85
Storage Temperature Range	-40 to + 100
Lead Soldering Temperature [1.6mm(.063") From Case]	260 for 5 Seconds
