LTC3731H

The LTC^®3731H is a PolyPhase^®synchronous step-down switching regulator controller that drives all N-channel external power MOSFET stages in a phase-lockable fixed frequency architecture. The LTC3731H is rated for opera-tion up to 140°C junction temperature. The 3-phase con-troller drives its output stages with 120° phase separation at frequencies up to 600kHz per phase to minimize the RMS current losses in both the input and output filter capacitors. The 3-phase technique effectively triples the fundamental frequency, improving transient response while operating each controller at an optimal frequency for efficiency and ease of thermal design. Light load efficiency is optimized by using a choice of output Stage Shedding or Burst Mode operation.

The precision reference supports output voltages from 0.6V to 6V. Current foldback provides protection for the exter-nal MOSFETs under short-circuit or overload conditions.Please refer to the LTC3731 data sheet for 0°C to 70°C and 40°C to 85°C rated versions.
