Features: High Efficiency: Up to 95%4A Output CurrentLow RDS(ON) Internal Switch: 67mWTracking Input to Provide Easy Supply SequencingProgrammable Frequency: 300kHz to 4MHz2.25V to 5.5V Input Voltage Range 2% Output Voltage Accuracy0.8V Reference Allows Low Output VoltageLow Dropout Operation: 100...
LTC3416: Features: High Efficiency: Up to 95%4A Output CurrentLow RDS(ON) Internal Switch: 67mWTracking Input to Provide Easy Supply SequencingProgrammable Frequency: 300kHz to 4MHz2.25V to 5.5V Input Voltag...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
The LTC (R)3416 is a high efficiency monolithic synchro- nous, step-down DC/DC converter utilizing a constant frequency, current mode architecture. It operates from an input voltage range of 2.25V to 5.5V and provides a regulated output voltage from 0.8V to 5V while delivering up to 4A of output current. The internal synchronous power switch with 67mW of on-resistance increases effi- ciency and eliminates the need for an external Schottky diode. Switching frequency is set by an external resistor. 100% duty cycle provides low dropout operation extend- ing battery life in portable systems. OPTI-LOOP(R) compen- sation allows the transient response to be optimized over a wide range of loads and output capacitors.
The LTC3416 operates in forced continuous operation and provides tracking of another power supply rail. Forced continuous operation reduces noise and RF interference and provides excellent transient response. Fault protection is provided by an overcurrent comparator, and adjustable compensation allows the transient response to be optimized over a wide range of loads and output capacitors.
