LPQ250

Features: • Active power factor correction• IEC EN61000-3-2 compliance• Remote sense on main output• Power fail and remote inhibit• Single wire current sharing• Built-in EMI filter• Adjustable floating 4th output• 2 Supervisory outputs 5 V and 12 V&#...

product image

LPQ250 Picture
See larger image
SeekIC No. : 004399222 Detail

LPQ250: Features: • Active power factor correction• IEC EN61000-3-2 compliance• Remote sense on main output• Power fail and remote inhibit• Single wire current sharing• B...

LPQ250 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
LPQ250
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Active power factor correction
• IEC EN61000-3-2 compliance
• Remote sense on main output
• Power fail and remote inhibit
• Single wire current sharing
• Built-in EMI filter
• Adjustable floating 4th output
• 2 Supervisory outputs 5 V and 12 V
• Overvoltage protection
• Overload protection
• Thermal overload protection
• DC power good
• 120 KHz switching frequency
• Cover -C
• Optional with fan cover -CF
• Optional end fan cover -CEF




Specifications

  • Total Max Power: 250 W
  • Total Max Current: 6 A
  • Input Voltage: 85 V to 264 V
  • Output Voltage: -15 V to - 5 V
  • Outputs: Quad
  • Size (L x W x H): 9.000" x 5.000" x 2.000"
  • Warranty: 2 years
  • Operating Temperature: 0 to +70 C
