LNJ951C4BRA: LED BLUE J TYPE SMD

LNJ951C4BRA Data Sheet

US $ .55~1.21 / Piece | Get Latest Price

Part Number:: LNJ951C4BRA
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~100
100~250
250~500
500~1000

Unit Price
$1.21
$.93
$.85
$.76
$.66
$.55

Processing time
15 Days
15 Days
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/5/16

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Product Details

Quick Details

Series:	-	Manufacturer:	Panasonic Electronic Components - Semiconductor Products
Color:	Blue	Millicandela Rating:	9mcd
Voltage - Forward (Vf) Typ:	3.2V	Current - Test:	5mA
Wavelength - Dominant:	-	Supply Current (Max) :	0.0023 mA
Wavelength - Peak:	470nm	Viewing Angle:	-
Lens Type:	Clear	Lens Style/Size:	Rectangle with Flat Top, 2.6mm x 1.6mm
Package / Case:	1208 (3020 Metric)	Size / Dimension:	3.20mm L x 1.60mm W
Height:	1.10mm	Mounting Type:	Surface Mount

Description

Series: -
Lens Type: Clear
Mounting Type: Surface Mount
Packaging: Cut Tape (CT)Alternate Packaging
Current - Test: 5mA
Wavelength - Dominant: -
Viewing Angle: -
Color: Blue
Voltage - Forward (Vf) Typ: 3.2V
Size / Dimension: 3.20mm L x 1.60mm W
Height: 1.10mm
Manufacturer: Panasonic Electronic Components - Semiconductor Products
Millicandela Rating: 9mcd
Package / Case: 1208 (3020 Metric)
Wavelength - Peak: 470nm
Lens Style/Size: Rectangle with Flat Top, 2.6mm x 1.6mm

Specifications

Lighting Color	P_D(mW)	I_F(mA)	I_FP(mA)*	V_R(V)	T_opr( )	T_stg( )
Blue	40	10	50	5	-25 ~ +80	-30 ~ +85

IFP,duty 10%,Pulse width 1 msec. The condition of IFP is duty 10%, Pulse width 1 msec

Parameters:

Technical/Catalog Information	LNJ951C4BRA
Vendor	Panasonic - SSG (VA)
Category	Optoelectronics
Color	Blue
Lens Style/Size	Rectangle, 2.6mm x 1.6mm
Millicandela Rating	9mcd
Voltage - Forward (Vf) Typ	3.2V
Wavelength - Dominant	470nm
Wavelength - Peak	470nm
Current - Test	5mA
Viewing Angle	140°
Lens Type	Clear
Luminous Flux	37 mlm
Package / Case	1208 (3020 metric)
Mounting Type	Surface Mount
Packaging	Cut Tape (CT)
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	LNJ951C4BRA LNJ951C4BRA P11127CT ND P11127CTND P11127CT
