SeekIC No. : 003613109 Detail

LN224RP: LED RED DIFFUSED

LN224RP Data Sheet

Get Latest Price

Part Number:: LN224RP
Mfg:
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

LN22 XCELITE evaluate
US $3.19 - 3.19 / Piece

SCRWDRIVER ALLEN HEX SOCKET TYPE
LN220RP evaluate
Specifications Lighting Color PD(mW) IF(mA) IFP(mA)* VR(V) Topr(°C) Tstg(°C) Red 70...
LN220RPH evaluate
Specifications LightingColor PD(mW) IF(mA) IFP(mA)* VR(V) Topr(°C) Tstg(°C)...

Product Details

Quick Details

Series:	-	Manufacturer:	Panasonic Electronic Components - Semiconductor Products
Color:	Red	Millicandela Rating:	0.6mcd
Voltage - Forward (Vf) Typ:	2.2V	Current - Test:	15mA
Wavelength - Dominant:	-	Wavelength - Peak:	700nm
Viewing Angle:	-	Lens Type:	Diffused, Tinted
Lens Style/Size:	Rectangle with Flat Top, 5mm x 1mm	Package / Case :	Micro
Package / Case:	Radial	Size / Dimension:	-
Height:	8.50mm	Mounting Type:	Through Hole

Description

Series: -
Voltage - Forward (Vf) Typ: 2.2V
Color: Red
Wavelength - Dominant: -
Viewing Angle: -
Size / Dimension: -
Lens Type: Diffused, Tinted
Package / Case: Radial
Mounting Type: Through Hole
Packaging: Bulk
Manufacturer: Panasonic Electronic Components - Semiconductor Products
Wavelength - Peak: 700nm
Current - Test: 15mA
Height: 8.50mm
Millicandela Rating: 0.6mcd
Lens Style/Size: Rectangle with Flat Top, 5mm x 1mm

Specifications

Lighting Color	P_D(mW)	I_F(mA)	I_FP(mA)*	V_R(V)	T_opr(°C)	T_stg(°C)
Red	70	25	150	4	-25 ~ +85	-30 ~ +100
Green	90	30	150	4	-25 ~ +85	-30 ~ +100
Amber	90	30	150	4	-25 ~ +85	-30 ~ +100

I_FP duty 10% Pulse width 1 msec. The condition of IFP is duty 10%, Pulse width 1 msec
