LMX5001

Operating Ambient Temperature ............................................0°C to +70°C
Storage Temperature .......................................................−65°C to +150°C
Maximum Input Voltage:
Inputs ............................................................................................VDD +0.5V
5V Tolerant................................................................................... VDD5 +0.5V
Maximum Operating Voltage ..................................................................3.6V
Note 2: Stresses beyond those listed under "Absolute Maximum Ratings"
may cause permanent damage to the device. This is a stress rating only and
functional operation of the device at these or any other conditions beyond
those indicated in the operational sections of this specification is not implied.
Exposure to absolute maximum rating conditions for extended periods may
affect device reliability.


Description

The LMX5001 Dedicated Bluetooth™ Link Controller has been designed to interface with the LMX3162, Single Chip Radio Transceiver to provide a rapid design path to a complete Bluetooth physical layer.

The LMX5001 also offers a low power and cost competitive solution to the Bluetooth Link Controller function. The LMX5001 can be attached to a Link Management Controller, or Host processor performing the Link Management function to implement a complete Bluetooth interface. Bluetooth is a world-wide recognized wireless communication standard, which operates in the ISM band (2.4 GHz), offering a low cost and convenient wireless replacement for data/voice cable links between fixed and mobile electronic devices.

Utilizing a GFSK modulation scheme, with frequency hopping, Bluetooth is able to offer a low power, low cost, robust and spectrally efficient spread spectrum packet data system.
