LM4700TF

The LM4700TF is one member of the LM4700 family which is designed as the audio power amplifier capable of delivering typically 30W of continuous average output power into an 8W load with less than 0.1% (THD + N). It can be used in compact stereo and component stereo. And it has an independent smooth transition fade-in/ out mute and a power conserving standby mode which can be controlled by external logic. Features of the LM4700TF are:(1)SPiKe Protection; (2)minimal amount of external components necessary; (3)quiet fade-in/out mute function; (4)power conserving standby-mode; (5)isolated 11-lead TO-220 package.

The absolute maximum ratings of the LM4700TF can be summarized as:(1)supply voltage |VCC|+|VEE| (no signal):66 V;(2)supply voltage |VCC|+|VEE| (with input and load):64 V;(3)common mode input voltage: (Vcc or VEE) and |Vcc|+|VEE| </= 60V;(4)differential input voltage:60 V;(5)output current:internally limited;(6)power dissipation:62.5 W;(7)ESD susceptibility:2000 V;(8)storage temperature:-40°C </= TA </= +150°C. If you want to know more information such as the electrical characteristics about the LM4700TF, please download the datasheet in www.seekic.com or www.chinaicmart.com .
