LM4570

PinoutSpecificationsSpecial FeaturesHaptic motor driver, 2.4ms Wakeup TimeSupply Min2.4 VoltSupply Max5.5 VoltShutdown TypeLowTemperature Min-40 deg CTemperature Max85 deg C View Using CatalogDescriptionThe LM4570 is a single supply motor driver for improved sensory experience in mobile phones and...

product image

LM4570 Picture
See larger image
SeekIC No. : 004395729 Detail

LM4570: PinoutSpecificationsSpecial FeaturesHaptic motor driver, 2.4ms Wakeup TimeSupply Min2.4 VoltSupply Max5.5 VoltShutdown TypeLowTemperature Min-40 deg CTemperature Max85 deg C View Using CatalogDescri...

LM4570 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
LM4570
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Pinout




Specifications

Special FeaturesHaptic motor driver, 2.4ms Wakeup Time
Supply Min2.4 Volt
Supply Max5.5 Volt
Shutdown TypeLow
Temperature Min-40 deg C
Temperature Max85 deg C
View Using Catalog



Description

The LM4570 is a single supply motor driver for improved sensory experience in mobile phones and other handheld devices. The LM4570 is capable of driving up to 192mA while operating from a 3V supply. Near rail-to-rail output swing under load ensures sufficient voltage drive for most DC motors, while the differential output drive allows the voltage polarity across the motor to be reversed quickly. Reversing the voltage gives the LM4570 the ability to drive a motor both clock-wise and counter clock-wise from a single supply.

The LM4570 features fast turn on time, and a wide input voltage range for precise speed control. A low power shutdown mode minimizes power consumption.

Thermal and output short circuit protection prevents the device from being damaged during fault conditions.

Reliability Metrics

Part Number Process EFR Reject EFR Sample Size PPM LTA Rejects LTA Device Hours FITS MTTF (Hours)
LM4570LQ CMOS7 0 16561 0 0 954000 4 270700104
LM4570LQX CMOS7 0 16561 0 0 954000 4 270700104

Note: The Early Failure Rates (EFR) were calculated as point estimate PPM based on rejects and sample size for EFR. The Long Term Failure Rates were calculated at 60% confidence using the Arrhenius equation at 0.7eV activation energy and derating the assumed stress temperature of 150°C to an application temperature of 55°C.

For more information on Reliability Metrics, please click here.
