LM385M3-2.5

Series VREF - Input Voltage (Max) :
Series VREF - Input Voltage (Min) :
Product : Voltage References
Topology : Shunt References
Reference Type : Precision
Packaging : Reel
Output Voltage : 2.5 V
Package / Case : SOT-23
Maximum Operating Temperature : + 70 C
Shunt Current (Max) : 20 mA
Initial Accuracy : 3 %
Average Temperature Coefficient (Typ) : 150 PPM/C


Pinout




Description

The LM385M3-2.5 is designed as one kind of micropower 2-terminal band-gap voltage regulator diode device that has some points of features:(1)±20 mV (±0.8%) max. initial tolerance (A grade); (2)Operating current of 20 A to 20 mA; (3)0.6W dynamic impedance (A grade); (4)Low temperature coefficient; (5)Low voltage reference-2.5V; (6)1.2V device and adjustable device also available-LM185-1.2 series and LM185 series, respectively.

The absolute maximum ratings of the LM385M3-2.5 can be summarized as:(1)Reverse Current: 30 mA;(2)Forward Current: 10 mA;(3)Operating Temperature Range: 0°C to 70°C;(4)Storage Temperature: -55°C to +150°C;(5)Soldering Information TO-92 package 10 sec.: 260°C;(6)Soldering Information TO-46 package 10 sec.: 300°C;(7)SO and SOT Package Vapor phase (60 sec.): 215°C;(8)SO and SOT Package Infrared (15 sec.): 220°C. If you want to know more information about the LM385M3-2.5, please download the datasheet in www.seekic.com or www.chinaicmart.com .
