LM2936M-5.0/NOPB, US $ .83-1.3 , National Semiconductor (TI), LM2936M-5.0/NOPB DataSheet download, circuit diagram from SeekIC.com

See larger image

SeekIC No. : 00508884 Detail

LM2936M-5.0/NOPB: Low Dropout (LDO) Regulators ULTRA-LOW QUIES CRNT LDO VLTG REG

LM2936M-5.0/NOPB Data Sheet

US $ .83~1.3 / Piece | Get Latest Price

Part Number:: LM2936M-5.0/NOPB
Mfg:: National Semiconductor (TI)
Supply Ability:: 5000

Price Break

Qty
0~1
1~25
25~100
100~250

Unit Price
$1.3
$1.04
$.94
$.83

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/11/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

LM2900D evaluate
US $.12 - .3 / Piece

Operational Amplifiers - Op Amps Quadruple Oper Amplifier
LM2900DE4 evaluate
US $.12 - .22 / Piece

Operational Amplifiers - Op Amps Quadruple Oper Amplifier
LM2900DG4 evaluate
US $.12 - .22 / Piece

Operational Amplifiers - Op Amps Quad Op Amp

Product Details

Quick Details

Input Voltage MAX :	40 V	Output Voltage :	5 V
Dropout Voltage (Max) :	0.1 V at 100 uA, 0.4 V at 50 mA	Output Current :	0.05 A
Load Regulation :	30 mV	Number of Outputs :	1
Output Type :	Fixed	Maximum Operating Temperature :	+ 125 C
Mounting Style :	SMD/SMT	Package / Case :	SOIC-8 Narrow

Description

Number of Outputs : 1
Maximum Operating Temperature : + 125 C
Mounting Style : SMD/SMT
Output Voltage : 5 V
Output Type : Fixed
Input Voltage MAX : 40 V
Load Regulation : 30 mV
Package / Case : SOIC-8 Narrow
Dropout Voltage (Max) : 0.1 V at 100 uA, 0.4 V at 50 mA
Output Current : 0.05 A

Parameters:

Technical/Catalog Information	LM2936M-5.0/NOPB
Vendor	National Semiconductor
Category	Integrated Circuits (ICs)
Regulator Type	Single Output
Package / Case	8-SOIC (3.9mm Width)
Packaging	Tube
Regulator Topology	Positive Fixed
Current - Output	50mA
Voltage - Output	5V
Operating Temperature	-40°C ~ 125°C
Voltage - Input	5.5 ~ 40 V
Number of Regulators	1
Current - Limit (Min)	-
Current Short Circuit (Isc)	65mA
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	LM2936M 5 0 NOPB LM2936M50NOPB LM2936M 5 0 ND LM2936M50ND LM2936M-5.0
