LM2903V

These devices LM2903V consist of two independent voltagecomparators that are designed to operate from asingle power supply over a wide range of voltages. Operation from dual supplies also is possible as long as the difference between the two supplies is
2 V to 36 V, and VCC is at least 1.5 V more positive than the input common-mode voltage. Current drain is independent of the supply voltage. The outputs can be connected to other open-collector outputs to achieve wired-AND relationships.
The LM2903V is characterized for operation from −55°C to 125°C. The LM293 and LM293A are characterized foroperation from −25°C to 85°C. The LM393 and LM393A are characterized for operation from 0°C to 70°C. The LM2903 is characterized for operation from −40°C to 125°C.
