Operating Supply Voltage
:
Mounting Style
:
Package / Case
:
Slew Rate
:
Shutdown
:
Output Current
:
Maximum Operating Temperature
:
Packaging
:
Common Mode Rejection Ratio (Min)
: 90 dB
Number of Channels
: 4
Input Bias Current (Max)
: 100 nA
Input Offset Voltage
: 5 mV
DescriptionThe LM148J is one member of the LM148 family which is designed as the quad 741 op amps that consists of four independent, high gain, internally compen-sated, low power operational amplifiers. This device can be used anywhere multiple 741 or 1558 type amplifiers are being used and in applications where amplifier matching or high packing density is required.
Features of the LM148J are:(1)741 op amp operating characteristics; (2)low supply current drain: 0.6 ma/amplifier; (3)class AB output stage-no crossover distortion; (4)pin compatible with the LM124; (5)low input offset voltage: 1 mV; (6)low input offset current: 4 nA; (7)low input bias current: 30 nA; (8)gain bandwidth product:LM148 (unity gain): 1.0 MHz and LM149 (AV >/= 5): 4 MHz; (9)high degree of isolation between amplifiers: 120 dB; (10)overload protection for inputs and outputs.
The absolute maximum ratings of the LM148J can be summarized as:(1)supply voltage:±22 V;(2)differential input voltage:±44 V;(3)output short circuit duration:continuous;(4)maximum junction temperature:150°C;(5)operating temperature range:-55°C </= TA </= +125°C;(6)storage temperature range:-65°C to +150°C;(7)lead temperature (soldering, 10 sec.) ceramic:300°C;(8)ESD tolerance:500 V. If you want to know more information such as the electrical characteristics about the LM148J, please download the datasheet in www.seekic.com or www.chinaicmart.com .
Parameters: | Technical/Catalog Information | LM148J |
| Vendor | National Semiconductor |
| Category | Integrated Circuits (ICs) |
| Packaging | Tube |
| Amplifier Type | General Purpose |
| Number of Circuits | 4 - Quad |
| Package / Case | 14-CDIP (300 mil) |
| Slew Rate | 0.5 V/s |
| Gain Bandwidth Product | 1MHz |
| Current - Supply | 2.4mA |
| Current - Output / Channel | 25mA |
| Voltage - Supply, Single/Dual (±) | 10 V ~ 44 V, ±5 V ~ 22 V |
| Output Type | - |
| -3db Bandwidth | - |
| Current - Input Bias | 30nA |
| Operating Temperature | -55°C ~ 125°C |
| Voltage - Input Offset | 1000V |
| Drawing Number | 14; J14A; ; 14 |
| Lead Free Status | Contains Lead |
| RoHS Status | RoHS Non-Compliant |
| Other Names | LM148J
