LED56

Infrared Emitters 1.5mW 1.7V IR LED

product image

LED56 Picture
See larger image
SeekIC No. : 0019028 Detail

LED56: Infrared Emitters 1.5mW 1.7V IR LED

LED56 Data Sheet

floor Price/Ceiling Price

US $ .66~1.03 / Piece | Get Latest Price
Part Number:
LED56
Mfg:
Fairchild Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $1.03
  • $.86
  • $.72
  • $.66
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Wavelength : 940 nm Beam Angle : +/- 10
Maximum Operating Temperature : + 125 C Minimum Operating Temperature : - 65 C
Package / Case : TO-46 Packaging : Bulk

Description

Radiant Intensity :
Packaging : Bulk
Wavelength : 940 nm
Maximum Operating Temperature : + 125 C
Package / Case : TO-46
Minimum Operating Temperature : - 65 C
Beam Angle : +/- 10


Features:

• Good optical to mechanical alignment
• Mechanically and wavelength matched to the TO-18 series phototransistor
• Hermetically sealed package
• High irradiance level


Specifications

Parameter Symbol Rating Unit
Operating Temperature TOPR -65 to +125
Storage Temperature TSTG -65 to +150
Soldering Temperature (Iron)(3,4,5 and 6) TSOL-I 240 for 5 sec
Soldering Temperature (Flow)(3,4 and 6) TSOL-F 260 for 10 sec
Continuous Forward Current IF 100 mA
Forward Current (pw, 1µs; 200Hz) IF 10 A
Reverse Voltage VR 3 V
Power Dissipation (TA = 25°C)(1) PD 170 mW
Power Dissipation (TC = 25°C)(2) PD 1.3 W
NOTE:
1. Derate power dissipation linearly 1.70 mW/°C above 25°C ambient.
2. Derate power dissipation linearly 13.0 mW/°C above 25°C case.
3. RMA flux is recommended.
4. Methanol or isopropyl alcohols are recommended as cleaning agents.
5. Soldering iron tip 1/16" (1.6mm) minimum from housing.
6. As long as leads are not under any stress or spring tension
7. Total power output, PO, is the total power radiated by the device into a solid angle of 2 # steradians.


Description

The LED55B/LED55C/LED56 are 940 nm LEDs in a narrow angle, TO-46 package.


Parameters:

Technical/Catalog InformationLED56
VendorFairchild Optoelectronics Group
CategoryOptoelectronics
Voltage - Forward (Vf) Typ1.7V
Current - DC Forward (If)100mA
Wavelength940nm
Viewing Angle16°
Radiant Intensity (Ie) Min @ If-
Mounting TypeThrough Hole
Package / CaseTO-46
OrientationTop View
PackagingBulk
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names LED56
LED56
