LC7573NM

Features: • 38 segment outputs• Noise reduction circuits are built into the output drivers.• Serial data input supports CCB* format communications with the system controller.• Switching between digital and analog dimmers under serial data control• High generality sinc...

product image

LC7573NM Picture
See larger image
SeekIC No. : 004392096 Detail

LC7573NM: Features: • 38 segment outputs• Noise reduction circuits are built into the output drivers.• Serial data input supports CCB* format communications with the system controller.•...

LC7573NM Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
LC7573NM
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/2

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• 38 segment outputs
• Noise reduction circuits are built into the output drivers.
• Serial data input supports CCB* format communications with the system controller.
• Switching between digital and analog dimmers under serial data control
• High generality since display data is displayed without the intervention of a decoder
• All segments can be turned off with the BLK pin


Pinout

Connection Diagram


Specifications

Parameter Symbol Conditions
Ratings
Unit
Maximum supply voltage VDDmax VDD
0.3 to +6.5
V
VFL max VFL
0.3 to +21.0
V
Input voltage VIN1 DI, CL, CE, BLK, DIM
0.3 to +6.5
V
VIN2 OSC
0.3 to VDD + 0.3
V
Output voltage VOUT1 S1 to S19, G1, G2
0.3 to VFL + 0.3
V
VOUT2 OSC
0.3 to VDD + 0.3
V
Output current IOUT1 S1 to S19
5
mA
IOUT2 G1, G2
30
mA
Allowable power dissipation Pdmax Ta = 85°C

150
mW
Operating temperature Topr
40 to +85
Storage temperature Tstg
50 to +125



Description

The LC7573N and LC7573NM are 1/2 duty VFD drivers that can be used for electronic tuning frequency display and other applications under the control of a controller. These products can directly drive VFDs with up to 38 segments.
