LC36256AL

Features: • Access time70 ns (max.) : LC36256AL-70, LC36256AML-7085 ns (max.) : LC36256AL-85, LC36256AML-85100 ns (max.) : LC36256AL-10, LC36256AML-10120 ns (max.) : LC36256AL-12, LC36256AML-12• Low current dissipationDuring standby2 A (max.) / Ta = 25°C5 A (max.) / Ta = 0 to +40°C25 A...

product image

LC36256AL Picture
See larger image
SeekIC No. : 004391611 Detail

LC36256AL: Features: • Access time70 ns (max.) : LC36256AL-70, LC36256AML-7085 ns (max.) : LC36256AL-85, LC36256AML-85100 ns (max.) : LC36256AL-10, LC36256AML-10120 ns (max.) : LC36256AL-12, LC36256AML-1...

LC36256AL Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
LC36256AL
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/5/28

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Access time
70 ns (max.) : LC36256AL-70, LC36256AML-70
85 ns (max.) : LC36256AL-85, LC36256AML-85
100 ns (max.) : LC36256AL-10, LC36256AML-10
120 ns (max.) : LC36256AL-12, LC36256AML-12
• Low current dissipation
During standby
2 A (max.) / Ta = 25°C
5 A (max.) / Ta = 0 to +40°C
25 A (max.) / Ta = 0 to +70°C
During data retention
1 A (max.) / Ta = 25°C
2 A (max.) / Ta = 0 to +40°C
10 A (max.) / Ta = 0 to +70°C
During operation (DC)
10 mA (max.)
• Single 5 V power supply: 5 V ±10%
• Data retention power supply voltage: 2.0 to 5.5 V
• No clock required (Fully static memory)
• All input/output levels are TTL compatible
• Common input/output pins, with three output states
• Packages
DIP 28 -pin (600 mil) plastic package : LC36256AL
SOP 28-pin (450 mil) plastic package : LC36256AML


Pinout

Connection Diagram


Specifications

Characteristic
Symbol
 Conditions
Ratings
Unit
Maximum supply voltage
VCCmax

7.0
V
Input pin voltage
VIN

0.5* to VCC+0.5
V
I/O pin voltage
VI/O

0.5* to VCC+0.5
V
Allowable power dissipation
PDmax
LC36256AL
1
W
LC36256AML
0.7
W
Operating temperature range
TOPR

0 to +70
°C
Storage temperature range
TSTG

55 to +150
°C


* 3.0 V when pulse width is less than 50 ns




Description

The LC36256AL, AML are fully asynchronous silicon gate CMOS static RAMs with an 32768 words × 8 bits configuration.

This series have CE chip enable pin for device select/nonselect control and an OE output enable pin for output control, and features high speed as well as low power dissipation.

For these reasons, the series is especially suited for use in systems requiring high speed, low power, and battery backup, and it is easy to expand memory capacity.
