LC19001A010

. Detects input coordinate values from resistive membrane pressure-sensitive digitizers at readout speeds up to 190
  points per second using a 10-bit A/D converter.
. Compact size, low power, and the 3.3 V power supply operation appropriate for PDAs and other portable information-processing equipment
. Menu area registration, duplicate coordinate processing, and 4-byte packets reduce the host CPU processing load.
. Logical exclusion of abnormal coordinates and averaging processing to remove both pen chattering noise and
  noise from the LCD system
.Controller functions can be programmed by sending command data from the host CPU.

Note: 1. The LC19001A010 must be used with AV_CC and V_CC at the same potential. Also, applications must assure that AV_CC does not exceed V_CC at power on.
2. VI and VO1 must not exceed V_CC + 0.3 V.

<Notes> This LSI can be permanently damaged by use at stresses in excess of the absolute maximum ratings. It is desirable that the LC19001A010 be operated within the recommended operating conditions during normal operation. In particular, the LSI's reliability may be adversely affected if these conditions are exceeded.

The LC19001A010 provides rapid and precise position detection for the resistive membrane pressure-sensitive digitizers used in PDAs and other portable informationprocessing equipment. It implements, in a single chip, the coordinate readout processing required for pen input operations.

This controller provides the following functions: digitizer voltage A/D conversion, noise exclusion, conversion to display coordinates, and data transfer to the host CPU.
