LB1638M

`Low voltage operation (2.5 V min.)
`Low saturation voltage (upper transistor + lower transistor
`residual voltage; at I<sub>O</sub> = 500 mA, V<sub>O</sub>(sat) = 0.75 V typ.)
`Low current drain at standby mode (I_CCO = 0.1 A typ. orless)
`Separate logic power supply and motor power supply
`Brake function .
`Built-in spark killer diodes
`Compact package (MFP-10S) suited for surface mounting.

The LB1638M, 1638M are low-saturation bidirectional motor driver ICs for use in low-voltage applications. At an I_O of 500 mA, they have a low saturation output of V_O (sat) =0.75 V. They are especially suited for use in compact motor of
portable equipment.
