Product Details

Description

Features:

· Height of display : 15 mm.
· Dimensions : 12.5 × 19 × 8 mm.
· Common anode and common cathode configurations are available.
· The package surface is coated black and the segments are milky white.
· High luminance, clear display.
· Red, green and orange displays are possible.

Specifications

Parametr	Symbol	Red	Green	Unit
Parametr	Symbol	LA-621MA/LMK	LA-621MA/LMK	Unit
Power dissipation	P_D	480	480	mW
Power dissipation	P_D/seg	60	60	mW
Forward current	I_F	20	20	mA
Peak forward current	I_FP	60(1)	60(1)	mA
Reverse voltage	V_R	3	3	V
Operating temperature	T_opr	-25~+75
Storage temperature	T_stg	-30~+85

(1)Pulse width 1ms duty 1/10

Description

The LA-621 AK series are two-color, high-luminance numeric displays designed to be used in bright locations. Red, green and orange displays are possible.
