L1117XG

Features: Fixed 1.8V, 2.5V, 2.85V, 3.3V, 5V or adjustable output voltage Low dropout voltage: 1.2V typical at up to 1A Low ground current Fast transient response Current & thermal limiting Line regulation: 0.5% typical Load regulation: 0.5% typical SOT-223,TO-220,TO-252,TO-263 packageApplicat...

product image

L1117XG Picture
See larger image
SeekIC No. : 004388717 Detail

L1117XG: Features: Fixed 1.8V, 2.5V, 2.85V, 3.3V, 5V or adjustable output voltage Low dropout voltage: 1.2V typical at up to 1A Low ground current Fast transient response Current & thermal limiting Line...

L1117XG Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
L1117XG
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

  Fixed 1.8V, 2.5V, 2.85V, 3.3V, 5V or adjustable output voltage
  Low dropout voltage: 1.2V typical at up to 1A
  Low ground current
  Fast transient response
  Current & thermal limiting
  Line regulation: 0.5% typical
  Load regulation: 0.5% typical
  SOT-223,TO-220,TO-252,TO-263 package


Application

2.85V active SCSI terminators
7-15V to 5V linear regulators
5V to 2.5V or 3.3V linear regulators
Low voltage micro-controllers
Battery Chargers
Motherboard clock supplies
Post regulator for switching supplies
Micro-controllers


Specifications

Maximum Supply Voltage                                     15V*
Power Dissipation                             Internally Limited
Thermal Resistance Junction to Case, JC      16 °C/W
Thermal Resistance Junction to Ambient, JA
SOT-223                  158 °C/W
TO-252                     70 °C/W
TO-220                     50 °C/W
TO-263                     60 °C/W
Operating Junction Temperature Range       0 to 125 °C
Storage Temperature Range                     -40 to 150 °C
Lead Temperature (Soldering, 10 Seconds)         260 °C




Description

The L1117G Series are positive and low drop- out three-terminal voltage regulators with 1A output current capability. These devices are designed for use in low voltage applica- tions that offers lower dropout voltage and faster transient response.

The L1117G Series  are fully protected against over current faults, over temperature oper- ation, reversed input polarity, reversed lead insertion, transient voltage spike .etc.

On-Chips trimming the reference voltage to 2% and features the low dropout of maxi- mum 1.45 volts.

The L1117G Series regulators offer fixed and adjustable voltage options available in the popular industry standard SOT-223, TO-220, TO-252 and TO-263 packages.
