KESRX05

The KESRX05 is a single chip ASK (Amplitude Shift Key) Receiver IC. KESRX05 is designed to operate in a variety of low power radio applications including keyless entry, general domestic and industrial remote control, RF tagging and local paging systems.

The receiver KESRX05 offers an exceptionally high level of integration and performance to meet the local oscillator radiation requirements of regulatory authorities world wide. Functionally the device works in the same way as the KESRX01 with the added features of low supply voltage, in-band interference rejection (anti-jamming detector), a 2-stage power down to enable receiver systems to be implemented with less than 1mA supply, and a wide IF bandwidth and drive stage to interface to an external ceramic IF bandpass filter at intermediate frequencies from 0·2MHz to 15MHz.

The KESRX05 is an ideal receiver for difficult reception areas where high level interferers would jam the wanted signal. The anti-jamming circuit allows operation to be possible with interfering signals which are more than 20dB stronger than the wanted signal, without the cost penalties of increased IF selectivity and frequency accuracy.
